SPEC:
Dimensions: 115x 70x 19 mm
Weight: 275g
System Platform: Ingenic X2000
System: In-House Developed
Display: Square 3-inch OLED Touch Screen 720p
DAC: ESS ES9039SPRO
Playback: MicroSD Card (up to 2TB), Tidal Online Streaming
Controls: Touch Screen, 4 Hardware Buttons, Volume Wheel
Remote Controls: SyncLink through Eddict Player app (Android & iOS)
Bluetooth Connectivity: TWO-Way Bluetooth5.2
Bluetooth Codec Support: LDAC/ aptX HD / aptX/ SBC / AAC
Wi-Fi Connectity: 2.4G/5G, DLNA, AirPlay, Tidal
USB DAC: Dedicated XMOS XU316 Chip
Hi-Res File Suppot: PCM 768kHz / 32bit, DSD512
Headphone Outputs: 3.5mm Single- Ended, 4.4mm Balanced
Battery: 7000 mAh, standard USB-C charging port
Battery life: Up to 14 hours SE, 12 hours BAL
File Support:
DSD (".iso",".dsf"," .dff" DST not supported) I5O/ DXD / APE / FLAC/ WAV
/AIFF1AIF/DTS/MP3/WMA/AAC/OGG/ALAC/MP2/M4A/AC3/
M3U/ M3U8/ OPUS
3.5mm Single-Ended Output
Output Power Low gain:
0.79V@32 (19mW@32) (THD+N<0.002% )
Output Power High gain:
3. 15V@32Ω (310mW@32 (THD+N<1%)
3.65V@300 ( 40mW@300) (THD+N<0.02%)
Frequency Response: 20Hz: .40kHz (-0.5dB)
THD+N: 0.0014% @32 (A-Weight)
Dynamic Range: 120dB @32 (A-Weight)
Channel Separation: 80dB
Signal-to-Noise Ratio: 120dB @32 (A-Weight)
Noise: 112dB @32
Output Impedance: 4.7
4.4mm Balanced Output
Output Power Low gain:
1.5V@32Ω (75mW@32Ω) (THD+N<0.0008%)
Output Power High gain:
5.7V@32Ω (1069mW@32Ω) (THD+N<1%)
6.9V@300Ω (1 58mW@300Ω) (THD+N<1%)
Frequency Response: 20Hz-40kHz (-0.5dB)
THD+N: 0.0006% @32Ω (A-Weight)
Dynamic Range: 121dB @32Ω (A-Weight)
Channel Separation: 100dB
Signal-to-Noise Ratio: 121dB @32Ω (A-Weight)
Noise: 109dB @32Ω (A-Weight)
Output Impedance: 6.6Ω
